| 顯示技術 | DLP 4K UHD chip DMD 0.65″ |
|---|---|
| 真實解析度 | 4K UHD (3840 × 2160) |
| 亮度 | 4,000 ANSI流明 |
| 對比度 | 1,200,000:1 |
| 光源類型 | 燈泡 |
| 投射比 | 1.21 – 1.59:1, ±3% |
| 光源壽命 | 4,000/10,000/15,000 hours (明亮 / 標準 / 動態) |
| 鏡頭變焦 | 1.3x 手動 |
| 鏡頭位移 | 105% – 115% ± 5% |
| 輸入/輸出入介面 | USB 1- USB 2.0, Power OUT (5V/1.5A) ,VGA In ,USB 2- USB 2.0, USB stick and WiFi dongle,RJ45,RS-232,HDMI 1 – V2.0 ( HDCP2.2 / 4K 60Hz / Support low latency),HDMI 2 – V2.0 ( HDCP2.2 / 4K 60Hz/ Support MEMC) ,USB 3 – USB 2.0 (USB stick and WiFi dongle),S/PDIF – Support PCM 2 channel,12V Out ,Audio In (Stereo, 3.5mm jack),Audio Out (Stereo, 3.5mm jack)HDMI 1.4a x1 HDMI 2.0/ HDCP2.2/ MHL 2.1 x1 VGA In x1 Audio In (stereo, 3.5mm jack) x1 USB-A (for 5V PWR 1.5A/ MStar firmware upgrade) x1 USB 2.0 (for firmware upgrade) x1 RS-232C male(9-pin D-SUB) x1 Audio Out 3.5mm x1 S/PDIF Out (2 Channel Stereo PCM) x1 12V Trigger(3.5mm jack) x1 |
| 喇叭 (Watts) | 10W |
| 重量(kg) | 3.9 ±0.5kg |
| 體積(寬×深×高)(mm) | 315 x 270 x115 mm (w/o feet), 315 x 270 x118 mm (w/ feet) |
| 投影比例 | 16:9 |
| 投影尺寸(對角線) | 34.1″ – 302.4″ |
| 投影鏡頭 | F#1.94~2.23, f 12.81~16.74mm |
| 均勻度 | 80% |
| 掃描頻率 | 水平31~135KHz, 垂直24 – 120Hz (1080p/240Hz at Enhanced Gaming Mode) |
| 可顯示色彩 | 1,073.4 百萬色(10 bit) |
| 3D 支援 | Full 3D |
| 噪音值 | 26 dB (Eco模式) |
| 電源規格 | 100240V, 5060Hz, auto-switching |
| 消耗功率 | <0.5W (standby), 336W (max) |
| RoHS | 相容 |
