All Specifications
Projection System
Projection System
DLP
DMD size
0.47″ ECD
Marketing
Main Marketing Series
Home Projector
Product Features
4K, HDR, HLG , 3D, RGBRGB, 95% DCI-P3, 100% Rec.709, Auto Vertical Keystone, CinemaMaster V+, CinemaMaster A+, ISF, 1.3x zoom
Display
Native Resolution
4K UHD (3840×2160)
Native Aspect Ratio
16:9
Brightness (ANSI lumens)
2000
Contrast Ratio (FOFO)
30,000:1
Selectable Aspect Ratio
16:9,4:3,Auto
Display Color
30-bit (1.07 billion colors)
Light Source
Lamp
Light Source Wattage
245W
Light Source Life
- Normal 4000 hrs,b. ECO 10000 hrs,c. SmartEco 15000 hrs
Optical
Throw Ratio
1.13~1.47
Zoom Ratio
1.3x
Lens
F/# = 1.9 – 2.47, f = 12 – 15.6 mm
Projection Offset (Full-Height)
100%
Keystone Adjustment
1D, (Auto) Vertical ± 30 degrees
Lens Shift Vertical
0%~+10%
ANSI Uniformity (Min.)
-45%
Clear Image Size
40″~200″
Image Size
30″~300″
Picture Modes
3D,Bright,Cinema,D. Cinema,HDR,HLG,ISF Day,ISF Night,Silence,User,Vivid TV
Color Wheel Segment (Lamp)
6 segment (RGBRGB)
Color Wheel Speed
100Hz,120Hz,3D (120Hz),96Hz
Rec. 709 Coverage
100%
DCI-P3 Coverage
95%
Compatibility
Input Lag
83.34ms (1080p@60Hz),83.34ms (4K@60Hz)
Resolution Support
VGA (640 x 480) to 4K UHD (3840 x 2160)
Horizontal Frequency
15K~135KHz
Vertical Scan Rate
23~120Hz
HDTV Compatibility
1080i,1080p,2160p,480i,480p,576i,576p,720p
3D Compatibility
Frame Packing (Blu-ray),Side by Side (Streaming),Top Bottom (Streaming)
I/O Interface
HDMI in
(x3),HDMI-1 (2.0b/HDCP2.2),HDMI-2 (2.0b/HDCP2.2),HDMI-Internal (2.0b/HDCP2.2)
USB Type A
N/A,USB Type A-1 (3.0/Power Supply1.0A/Reader),USB Type A-3 (2.0/Power Supply2.5A)
USB Type Mini B
(x1),USB Type Mini B-1(service)
RS232 in (DB-9pin)
(x1)
DC 12V Trigger (3.5mm Jack)
(x1)
Audio
Speaker
(x2),5W Chamber
Audio out (3.5mm Mini Jack)
(x1)
Audio EQ
Yes
Audio L/R Switch
Yes
Environment
Power Supply
AC 100 to 240 V, 50/60 Hz
Typical Power Consumption (110V)
330W
Stand-by Power Consumption
<0.5W
Acoustic Noise (Typ./Eco.)(dB)
30/28
Operating Temperature
0~40℃
Accessories
Android TV dongle
(Standard),QS01
Remote Control w/ Battery
RCI067,RCV017
Power Cord (by region)
(Standard),x1 (3.0M)
3D Glasses
(Optional),DGD5
Quick Start Guide
1 (21L)
Warranty Card (by region)
Yes
Lens cover
Yes
Universal Ceiling Mount
(Standard),CMG3
OSD
OSD Language
28L
Smart System
Built-in OS
Yes, Android 9.0
ROM/RAM
16GB/2GB
Bluetooth
Yes, Bluetooth 4.2
Wi-Fi Standard
802.11 a/b/g/n/ac (2.4G/5G)
Wireless Projection
Google Cast
Dimension & Weight
Dimensions (WxHxD) (mm)
380 x 127 x 263
Dimensions (WxHXD) (inch)
14.96 x 4.99 x 10.35
Net Weight (kg)
4.2
Net Weight (lb)
9.25
* In 3D Mode: Resolution is 1920×1080 in 3D Mode.
** The Contrast is measured by Full On Full Off standard.
*** Lamp life results will vary depending on environmental conditions and usage. Actual product’s features and specifications are subject to change without notice.
